CombiMax J-1015
The Max 15 J-1015 by Pilot Machinery is a combined Surfacer and Thicknesser machine, designed for professionals who value precision and multi-functionality in their woodworking projects. Like its counterpart Combimax, Max 15 J-1015 combines surfacing and thicknessing capabilities in one powerful machine but with a fixed top. This machine is perfect for a professional setup, delivering high accuracy and smooth performance for both small and large-scale woodworking operations.
Model Numbers: J-1014, J-1014L, J-1015, J-1015L, J-1019, J-1025
Max 15 is available in various models, each with different table lengths to accommodate diverse woodworking needs. The “L” models feature extended tables for handling larger workpieces.
USPs of the CombiMax J-1015
Multi-Functional
Max 15 serves as both a surfacer and thicknesser, making it a highly versatile and cost-effective solution for professional woodworking tasks.
Fixed Top Design
Unlike other models, Max 15 J-1015 comes with a fixed top, providing additional stability and precision for consistent performance.
Robust Construction
Built with high-quality materials, Max 15 ensures durability and long-lasting reliability, even in heavy-duty applications.
Multiple Models
Available in several models with optional longer table lengths to suit a variety of operational needs.
Essential Standard Accessories
Comes equipped with essential accessories like planer blades, motor pulley, and safety guards for seamless woodworking operations.
Model | Max-13 J-1014 | Max-13 J-1014L | Max-15 J-1015 | Max-15 J-1015L | Max-18 J-1019 | Max-24 J-1025 |
mm / inch | mm / inch | mm / inch | mm / inch | mm / inch | mm / inch | |
Surfacing capacity | 330 / 13" | 330 / 13" | 381 / 15" | 381 / 15" | 455 / 18" | 610 / 24" |
Max planing width | 330 / 13" | 330 / 13" | 381 / 15" | 381 / 15" | 455 / 18" | 610 / 24" |
Thicknessing capacity | 177 / 7" | 177 / 7" | 177 / 7" | 177 / 7" | 177 / 7" | 177 / 7" |
Length Of surface Table | 1220 / 48" | 1550 / 61" | 1295 / 51" | 1550 / 61" | 1550 / 61" | 1550 / 61" |
Rebating Capacity | 12.5 / ½" | 12.5 / ½" | 12.5 / ½" | 12.5 / ½" | 12.5 / ½" | 12.5 / ½" |
Length Of Thickness Table | 640 / 25¼" | 640 / 25¼" | 710 / 28" | 710 / 28" | 735 / 29" | 800 / 31½" |
Min. Length of workpiece for thicknessing | 254 / 10" | 254 / 10" | 254 / 10" | 254 / 10" | 254 / 10" | 254 / 10" |
Feeding Speed (feet per minute) | 24 | 24 | 24 | 24 | 24 | 24 |
Cutter block diameter | 95 / 3.75" | 95 / 3.75" | 95 / 3.75" | 95 / 3.75" | 105 / 4.15" | 120 / 4.72" |
Cutter block speed- RPM | 4000 | 4000 | 4000 | 4000 | 4000 | 4000 |
Standard cutter block - code no. | 2B | 2B | 2B | 2B | 3B-W | 3B-W |
Circular saw table size | 610 x 305 / 24" x 12" | 610 x 305 / 24" x 12" | 610 x 305 / 24" x 12" | 610 x 305 / 24" x 14" | 610 x 305 / 24" x 14" | 610 x 305 / 24" x 14" |
Up/Down movement of Cir.saw table | 75 / 3" | 75 / 3" | 75 / 3" | 75 / 3" | 75 / 3" | 75 / 3" |
Max.circular saw diameter | 300 / 12" | 300 / 12" | 300 / 12" | 300 / 12" | 300 / 12" | 300 / 12" |
Power required - HP / RPM | 3 / 1440 | 3 / 1440 | 3 / 1440 | 3 / 1440 | 5 / 1440 | 5 / 1440 |
Approx.wt.of machine - kg. | 400 | 425 | 450 | 475 | 600 | 750 |
Standard Accessories :-
- 2/3 planer blades fitted in the cutter block
- Mitre gauge
- Motor pulley
- Motor fixing plate
- Toolkit
- Machine manual
- L = Machine with 61" table length
Inter Changeable Attachments
Model No: D
Drilling
Model No:13-G, 18-G
Blade Grinding
Model No: M
Moulding (auto Feed)
Why Choose us
Largest range of global manufacturers
Ensuring you a wide range of choices, for maximum success, suited to your needs.
Readily Available Spare Parts
At Pilot Machinery, we prioritize minimizing downtime and ensuring your operations run smoothly.
Expertly Trained Service Engineers
Our team of skilled service engineers is dedicated to delivering top-notch support and maintenance.
Trusted Industry Leader
Pilot Machinery has earned a reputation for reliability and exceptional quality.
Frequently Asked Questions
Max 15 J-1015 is a combined Surfacer and Thicknesser machine, designed for precision and multi-functionality in woodworking tasks. It features a fixed top for added stability and is ideal for professional use.
Max 15 J-1015 works by first surfacing and then thicknessing the wood, offering a smooth and accurate finish. It is engineered for reliability and precision, handling both small-scale and large-scale projects efficiently.
The available models for Max 15 are J-1014, J-1014L, J-1015, J-1015L, J-1019, and J-1025, with options for extended table lengths in the “L” models.
Yes, Max 15 J-1015 comes with a range of standard accessories including planer blades, mitre gauge, motor pulley, toolkit, and more, ensuring that the machine is ready for immediate use.
Yes, optional attachments like the D Drilling, Blade Grinding, and M Moulding attachments can be ordered at any time to enhance the machine’s capabilities.
